The YH40-30C is a high-performance 4-axis engraving machine designed by Anhui Yuhan, a leading manufacturer in CNC technology. Combining advanced automation with precision engineering, this machine caters to both industrial production and small-scale workshops.
| Availability: | |
|---|---|
| Quantity: | |
Its robust build and versatile functionality make it ideal for processing a wide range of materials, from soft woods to hard metals. With a focus on durability and accuracy, the YH40-30C stands out for its 0.02mm reposition precision and 0.03mm/300mm mechanical accuracy, ensuring consistent results even in complex engraving tasks. Whether for 3D relief carving or intricate 4-axis operations, this machine delivers reliability and efficiency, supported by a user-friendly WEIHONG NK105 G3 operating system.
Parameter | Details |
Model NO. | YC4030A |
Application Material | acrylic/stone/jade/wood/aluminum/copper |
Automation | Automatic |
Motor Power | High Power |
Current | AC |
Voltage | 380V /220V |
Customized | Customized |
Reposition Precision | 0.02mm |
Operation System | WEIHONG NK105 G3 |
Command | NC/ENG |
Water Cooling Spindle Power | 1.5kw/2.2kw |
Spindle Speed | 0-24000rpm |
Machine Type | Four-Axis |
Working Size (Relief) | 200250130 MM |
Working Size (3D) | 220*170 MM |
Motor Driver | Stepper motor driver (Chinese servo motor and Japan servo motor optional) |
Tool Diameter | 3.175、4、6mm |
Relative Humidity | 30%-75% |
Running Environment Temperature | 0-45ºC |
XYZ Rails | Square Rails |
A-Axis | Reduction gear |
Dust-proof System | X/Y/Z high quality dust cover |
Mechanical Accuracy | 0.03/300mm |
Support Format | NC / ENG |
Working Voltage | AC220V/50Hz or 380V/50Hz |
Machine Size | 7608601620 MM |
Net Weight | 280 KG |
The integrated water cooling system regulates spindle temperature during extended operations, significantly extending cutter lifespan and maintaining consistent performance. This feature is crucial for handling high-intensity tasks without overheating.
Equipped with breakpoint and power failure recovery functions, the machine resumes carving from exactly where it left off. This minimizes material waste and ensures project timelines are met, even in unexpected power disruptions.
A dust-proof oiling structure protects mechanical components from debris and wear, reducing maintenance needs and ensuring long-term reliability. The industrial-grade frame uses heavy all-steel welded construction with tempering aging treatment, preventing deformation and ensuring stability over years of use.
Key configurations utilize imported and joint-venture brand parts, from motor drivers to rails, ensuring stable performance. Optional Chinese or Japanese servo motors allow customization based on precision and budget requirements.
With 0.02mm reposition precision and 0.03mm/300mm mechanical accuracy, the YH40-30C delivers intricate details, making it suitable for fine engraving on delicate materials like jade and copper.
· Acrylic: Ideal for signage, decorative panels, and precision parts.
· Stone/Jade: Perfect for jewelry, sculptures, and cultural artifacts.
· Wood: Suitable for furniture detailing, musical instruments, and crafts.
· Aluminum/Copper: Used in industrial components, electrical parts, and custom metalwork.
· Jewelry Making: Creates intricate designs on jade, copper, and precious metals.
· Advertising: Produces high-precision acrylic signs and displays.
· Woodworking: Adds detailed carvings to furniture and wooden crafts.
· Metal Fabrication: Engraves serial numbers, logos, and designs on aluminum and copper parts.
The machine offers a 200*250*130 MM working size for relief carving and 220*170 MM for 3D engraving, accommodating a wide range of project scales.
Yes, its high-power motor and versatile tool compatibility (3.175mm, 4mm, 6mm diameters) allow it to process soft materials like wood and acrylic, as well as harder substances such as stone, aluminum, and copper.
Absolutely. Customers can choose between stepper motor drivers, Chinese servo motors, or Japanese servo motors based on their precision needs. Voltage options (220V/380V) also ensure compatibility with global power standards.
It runs on the WEIHONG NK105 G3 system, a user-friendly platform that supports NC/ENG formats, simplifying file uploads and operation for both beginners and professionals.
The net weight is 280 KG, providing stability during operation. While no specialized installation is needed, ensuring a level surface and proper power supply (matching 220V or 380V) is recommended for optimal performance.
