The YH40-40X is a cutting-edge three-axis engraving machine manufactured by Anhui Yuhan Numerical Control Technology Co., Ltd., a leading enterprise in the field of numerical control technology since 2014. This high-performance machine is designed to deliver precise and efficient engraving results across a wide range of materials. With its advanced features and robust construction, it stands out as a reliable solution for both industrial production and customized engraving needs.
| Availability: | |
|---|---|
| Quantity: | |
Boasting a working size of 380380130 MM, the YH40-40X offers ample space for various engraving projects. Its high-power motor ensures strong performance, while the WEIHONG NK105 G3 operation system guarantees smooth and accurate operation. Whether you're working on small-scale DIY projects or large industrial productions, this machine is capable of meeting diverse requirements.
Parameter | Details |
Model NO. | YH40-40X |
Application Material | acrylic/stone/jade/wood/aluminum/copper |
Automation | Automatic |
Motor Power | High Power |
Current | AC |
Voltage | 380V /220V |
Customized | Customized |
Reposition Precision | 0.02mm |
Operation System | WEIHONG NK105 G3 |
Command | NC/ENG |
Water Cooling Spindle Power | 1.5kw/2.2kw |
Spindle Speed | 0-24000rpm |
Machine Type | Three-Axis |
Working Size | 380380130 MM |
Motor Driver | Stepper motor driver (Chinese servo motor and Japan servo motor is optional) |
Tool Diameter | 3.175、4、6mm |
Relative Humidity | 30%-75% |
Running Environment Temperature | 0-45ºC |
XYZ Rails | Square Rails |
Dust-proof System | X/Y/Z high quality dust cover |
Mechanical Accuracy | 0.03/300mm |
Support Format | NC / ENG |
Working Voltage | AC220V/50Hz or 380V/50Hz |
Machine Size | 7609001620 MM |
Net Weight | 300 KG |
The YH40-40X comes with a range of specifications that contribute to its exceptional performance. The 0.02mm reposition precision ensures that each engraving is accurate, while the 0-24000rpm spindle speed allows for flexibility in handling different materials and engraving tasks. The option to choose between stepper motor driver, Chinese servo motor, and Japan servo motor provides users with the ability to select the best fit for their specific needs.
The water cooling system is a key feature of the YH40-40X. It efficiently regulates the temperature of the cutter, ensuring that it remains in optimal condition even during prolonged use. This not only extends the lifespan of the cutter but also maintains the quality of the engraving throughout the process.
This machine is equipped with a breakpoint and power failure resume function. In the event of a power outage or unexpected interruption, the machine can resume the engraving process from where it left off. This eliminates the need to restart the entire project, saving both time and materials.
The dust-proof system, featuring high-quality dust covers for X, Y, and Z axes, prevents dust and debris from entering critical components. Additionally, the dust oiling structure ensures that the mechanical parts are properly lubricated, guaranteeing long-term smooth operation and reducing maintenance requirements.
Main configurations of the YH40-40X are sourced from imported and joint venture brands. This ensures stable and reliable performance, even in demanding working environments. The use of top-grade components contributes to the machine's durability and consistent results.
The machine body adopts an industrial production model with a heavy all-steel welded structure. After tempering and aging treatment, it exhibits strong non-deformation properties, making it durable for long-term use. This robust construction provides a stable platform for precise engraving.
· Acrylic: Ideal for creating intricate designs on acrylic sheets, which are widely used in signage, displays, and decorative items.
· Stone: Capable of engraving on various types of stone, making it suitable for producing stone carvings, monuments, and architectural decorations.
· Jade: With its high precision, the machine can craft detailed jade carvings, perfect for jewelry, ornaments, and collectibles.
· Wood: Suitable for wood engraving, used in furniture decoration, wooden crafts, and artistic creations.
· Aluminum and Copper: Can handle metal engraving tasks, such as creating nameplates, industrial parts, and decorative metal items.
· Jewelry Industry: Used for engraving intricate patterns on jewelry pieces made from jade, metal, and other materials.
· Advertising Industry: Produces high-quality signage and displays on acrylic and other materials.
· Crafts Industry: Enables the creation of detailed wooden, stone, and metal crafts.
· Industrial Manufacturing: Engraves marks and patterns on metal parts for identification and decoration.
Yes, the YH40-40X is customizable. Customers can choose between different motor drivers, including stepper motor driver, Chinese servo motor, and Japan servo motor, to meet their specific requirements.
The reposition precision of the YH40-40X is 0.02mm, ensuring high accuracy in every engraving project.
The machine can handle a variety of materials, including acrylic, stone, jade, wood, aluminum, and copper.
The working voltage options are AC220V/50Hz or 380V/50Hz, providing flexibility for different power supply conditions.
Yes, it is equipped with an X/Y/Z high-quality dust cover, which effectively protects the mechanical components from dust and debris, ensuring long-term reliable operation.
The spindle speed ranges from 0 to 24000rpm, allowing for efficient engraving on various materials.
The net weight of the machine is 300 KG, which contributes to its stability during operation.
