The YH60-35 is a professional 3-axis engraving machine designed for precision processing across diverse materials, including acrylic, stone, jade, wood, aluminum, and copper.
| Availability: | |
|---|---|
| Quantity: | |
With a compact working size of 600×350 mm and advanced features like a water cooling system and breakpoint recovery function, it balances efficiency and durability—ideal for small to medium-scale production or craftsman workshops. Its robust all-steel welded structure ensures stable performance, while customizable components (such as servo motors) allow adaptation to specific workflow needs.
Parameter | Detail | Parameter | Detail |
Model NO. | YH60-35 | Working Size (3D) | 600×350 mm |
Machine Type | Three-Axis | Reposition Precision | 0.02mm |
Automation | Automatic | Mechanical Accuracy | 0.03/300mm |
Spindle Power | 2.2kw (water cooling) | Spindle Speed | 0-24000rpm |
Voltage | AC 220V/50Hz or 380V/50Hz | Motor Driver | Stepper (Chinese/Japanese servo optional) |
Tool Diameter | 3.175, 4, 6, 8, 10, 12mm | Operation System | WEIHONG NK105 G3 |
Machine Size | 730×600×1580 mm | Net Weight | 420 KG |
Running Temperature | 0-45ºC | Relative Humidity | 30%-75% |
Equipped with a water cooling spindle, the machine maintains optimal operating temperatures even during extended use, significantly extending cutter lifespan and reducing maintenance frequency.
Integrated breakpoint and power failure recovery functions ensure uninterrupted work—critical for complex projects that require hours of processing. This feature minimizes material waste and rework.
The dust-proof system (including high-quality X/Z axis dust covers) and precision square rails protect internal components from debris, ensuring consistent performance over long-term use.
Key parts are sourced from reputable international and joint-venture brands, with options for Japanese servo motors to enhance precision for high-demand applications like jade carving.
The heavy-duty all-steel welded frame undergoes tempering aging treatment, eliminating deformation risks and ensuring mechanical stability even under high-speed operation.
· Jade & Stone: Achieves intricate detailing with 0.02mm reposition precision, ideal for jewelry or decorative stone crafts.
· Wood & Acrylic: Smooth cutting and engraving on soft materials, suitable for furniture decorations, signage, or acrylic displays.
· Metal (Aluminum/Copper): Handles thin metal sheets with high power spindle, supporting custom part manufacturing or nameplate engraving.
· Crafts & Artwork: Perfect for artisans creating personalized gifts or artistic carvings.
· Small-Scale Production: Efficiently processes batches of components for electronics, furniture, or jewelry industries.
It supports acrylic, stone, jade, wood, aluminum, copper, and other non-ferrous metals.
Yes, it uses the WEIHONG NK105 G3 system, which is user-friendly with intuitive controls for beginners.
Yes, Chinese or Japanese servo motors are optional for higher precision needs.
It works with AC 220V or 380V (50Hz), adaptable to different regional power supplies.
Regularly clean dust covers, check lubrication on rails, and ensure the water cooling system is filled—detailed guidelines are provided in the user manual.
