The YH400 is a high-performance automatic stone cutting machine manufactured by Anhui Yuhan Numerical Control Technology Co., Ltd. As a three-axis equipment, it is engineered to provide precise and efficient cutting operations for a wide range of materials. With its advanced automation features and robust construction, the YH400 has become a reliable choice in the stone processing industry.
| Availability: | |
|---|---|
| Quantity: | |
Equipped with a powerful motor and an efficient operation system, this machine ensures consistent performance even during long working hours. Its high reposition precision of 0.04mm and mechanical accuracy of 0.03/300mm make it suitable for applications that demand extreme precision. Whether handling stone, jade, or meteorite, the YH400 delivers exceptional results, meeting the diverse needs of various industries.
Parameter | Details |
Model NO. | YH400 |
Application Material | Stone/Jade/Meteorite/ |
Automation | Automatic |
Motor Power | High Power |
Current | AC |
Voltage | 380V /220V |
Customized | Customized |
Reposition Precision | 0.04mm |
Operation System | WEIHONG NK105 G3 |
Speed | 60mm/hour |
Machine Type | Three-Axis |
Working Size | 400*400 MM |
Motor Driver | Stepper motor driver(Chinese servo motor and Japan servo motor is optional) |
Wire Diameter | 0.28、0.3、0.38、0.42、0.45mm |
Relative Humidity | 30%-75% |
Running Environment Temperature | 0-45ºC |
X Y Rails | Square Rails |
Dust-proof System | X/Y high quality dust cover |
Mechanical Accuracy | 0.03/300mm |
Working Voltage | AC220V/50Hz or 380V/50Hz |
Machine Size | 14007601650 MM |
Net Weight | 760 KG |
The integrated water cooling system plays a crucial role in maintaining the cutter's performance. By effectively dissipating heat generated during the cutting process, it significantly extends the cutter's service life, reducing the frequency of replacements and ensuring continuous operation.
This machine is equipped with a breakpoint and power failure continued carving function. In the event of unexpected interruptions such as power outages, it can resume the cutting process from the exact point where it stopped. This feature not only saves time but also minimizes material waste, improving overall work efficiency.
The dust oiling structure is designed to keep the mechanical components in optimal condition. It prevents dust and debris from entering critical parts, while the lubrication system ensures smooth operation. This effectively guarantees the long-term stable running of the mechanical aspects, reducing maintenance requirements.
Main configurations of the YH400 are selected from imported and joint venture brand components. These high-quality parts contribute to the machine's stable and reliable performance, ensuring consistent results even in demanding working environments.
The machine body adopts an industrial production model with a heavy all-steel welded structure. Through tempering aging treatment, it achieves strong non-deformation properties, making it highly durable and capable of withstanding long-term heavy use.
· Stone: The YH400 is widely used for cutting various types of stone, including marble, granite, and limestone. Its precision cutting capabilities allow for the creation of intricate shapes and sizes, meeting the requirements of construction and decoration projects.
· Jade: In the jade processing industry, this machine excels at cutting jade into desired forms for jewelry making, handicrafts, and other jade-related products. The high precision ensures that the valuable jade material is utilized efficiently.
· Meteorite: Due to its unique properties, meteorite requires precise cutting, which the YH400 can provide. It is suitable for research institutions and collectors who need to process meteorite samples.
· Construction and Decoration: Used in the production of stone tiles, panels, and decorative elements, contributing to the creation of beautiful and functional building interiors and exteriors.
· Jewelry Making: Essential for cutting jade and other precious stones into shapes suitable for jewelry design and production.
· Cultural and Handicraft Industries: Enables the precise cutting of materials for the creation of various handicrafts, sculptures, and cultural artifacts.
Yes, the YH400 offers customized options. Customers can choose between Chinese servo motor and Japan servo motor for the motor driver, depending on their specific needs and budget.
The working voltage of the YH400 can be either AC220V/50Hz or 380V/50Hz, providing flexibility to adapt to different power supply conditions in various regions.
The YH400 boasts a reposition precision of 0.04mm and a mechanical accuracy of 0.03/300mm, ensuring high-precision cutting operations for even the most demanding applications.
The machine operates at a speed of 60mm/hour, balancing efficiency and precision to meet the needs of different production schedules.
The YH400 has a machine size of 14007601650 MM and a net weight of 760 KG, making it a substantial piece of equipment that requires proper installation and placement in the workshop.
Equipped with a powerful motor and an efficient operation system, this machine ensures consistent performance even during long working hours. Its high reposition precision of 0.04mm and mechanical accuracy of 0.03/300mm make it suitable for applications that demand extreme precision. Whether handling stone, jade, or meteorite, the YH400 delivers exceptional results, meeting the diverse needs of various industries.
Parameter | Details |
Model NO. | YH400 |
Application Material | Stone/Jade/Meteorite/ |
Automation | Automatic |
Motor Power | High Power |
Current | AC |
Voltage | 380V /220V |
Customized | Customized |
Reposition Precision | 0.04mm |
Operation System | WEIHONG NK105 G3 |
Speed | 60mm/hour |
Machine Type | Three-Axis |
Working Size | 400*400 MM |
Motor Driver | Stepper motor driver(Chinese servo motor and Japan servo motor is optional) |
Wire Diameter | 0.28、0.3、0.38、0.42、0.45mm |
Relative Humidity | 30%-75% |
Running Environment Temperature | 0-45ºC |
X Y Rails | Square Rails |
Dust-proof System | X/Y high quality dust cover |
Mechanical Accuracy | 0.03/300mm |
Working Voltage | AC220V/50Hz or 380V/50Hz |
Machine Size | 14007601650 MM |
Net Weight | 760 KG |
The integrated water cooling system plays a crucial role in maintaining the cutter's performance. By effectively dissipating heat generated during the cutting process, it significantly extends the cutter's service life, reducing the frequency of replacements and ensuring continuous operation.
This machine is equipped with a breakpoint and power failure continued carving function. In the event of unexpected interruptions such as power outages, it can resume the cutting process from the exact point where it stopped. This feature not only saves time but also minimizes material waste, improving overall work efficiency.
The dust oiling structure is designed to keep the mechanical components in optimal condition. It prevents dust and debris from entering critical parts, while the lubrication system ensures smooth operation. This effectively guarantees the long-term stable running of the mechanical aspects, reducing maintenance requirements.
Main configurations of the YH400 are selected from imported and joint venture brand components. These high-quality parts contribute to the machine's stable and reliable performance, ensuring consistent results even in demanding working environments.
The machine body adopts an industrial production model with a heavy all-steel welded structure. Through tempering aging treatment, it achieves strong non-deformation properties, making it highly durable and capable of withstanding long-term heavy use.
· Stone: The YH400 is widely used for cutting various types of stone, including marble, granite, and limestone. Its precision cutting capabilities allow for the creation of intricate shapes and sizes, meeting the requirements of construction and decoration projects.
· Jade: In the jade processing industry, this machine excels at cutting jade into desired forms for jewelry making, handicrafts, and other jade-related products. The high precision ensures that the valuable jade material is utilized efficiently.
· Meteorite: Due to its unique properties, meteorite requires precise cutting, which the YH400 can provide. It is suitable for research institutions and collectors who need to process meteorite samples.
· Construction and Decoration: Used in the production of stone tiles, panels, and decorative elements, contributing to the creation of beautiful and functional building interiors and exteriors.
· Jewelry Making: Essential for cutting jade and other precious stones into shapes suitable for jewelry design and production.
· Cultural and Handicraft Industries: Enables the precise cutting of materials for the creation of various handicrafts, sculptures, and cultural artifacts.
Yes, the YH400 offers customized options. Customers can choose between Chinese servo motor and Japan servo motor for the motor driver, depending on their specific needs and budget.
The working voltage of the YH400 can be either AC220V/50Hz or 380V/50Hz, providing flexibility to adapt to different power supply conditions in various regions.
The YH400 boasts a reposition precision of 0.04mm and a mechanical accuracy of 0.03/300mm, ensuring high-precision cutting operations for even the most demanding applications.
The machine operates at a speed of 60mm/hour, balancing efficiency and precision to meet the needs of different production schedules.
The YH400 has a machine size of 14007601650 MM and a net weight of 760 KG, making it a substantial piece of equipment that requires proper installation and placement in the workshop.
